Rittal 7979.310 16A 3,7KW High-end IT Rack Power Distribution PDU 6x C13 1x C19

Rittal

Rittal 7979.310 16A 3,7KW High-end IT Rack Power Distribution PDU 6x C13 1x C19

Model: 7979.310

Cable Length / Kabellänge: 3m


Technical data / Technische Daten

Manufacturer / Hersteller

Rittal

Type / Gerätetyp

Power Distribution Unit (PDU)

Case / Gehäuse

Plugbar / Steckerleiste

Input Connections / Eingangsanschlüsse

230 V, 16A, 50/60 Hz

Output Connections / Ausgangsanschlüsse

6 x C13 Sockets / Buchsen
1 x C19 Socket / Buchse

Interfaces / Schnittstellen

1 x RJ-45 Ethernet 10/100/1000 Base-T
1 x RJ-45 Ethernet 10/100/1000 Base-T (PoE)
1 x RJ-12 RS-232
1 x RJ-45 CAN
1 x USB 2.0

Technical Specifications / Technisch Daten

Display/controller unit in the PDU enclosure rotatable through 180° and replaceable
Integral, fully-redundant power pack, power supply from all phases
Error-tolerant PDU power supply redundant across all phases
Voltage V, current A, frequency Hz
Active power, active energy, apparent power, apparent energy
Power factor (cosPhi) and phase angle
Zero conductor current measurement/load imbalance detection
Fuse monitoring for PDUs with integral fuse
Monitoring of the optionally available overvoltage protection
Bright TFT display, 128 x 128 pixels (RGB) with back-lighting and energy-saving mode to display output data and basic PDU configuration
Position sensors for display rotation and correct PDU representation on the website
Multi-colour LEDs (green/amber/red) to indicate switching states and warning/alarm limits per phase or infeed
Power LED to indicate voltage
Power-saving design, minimal intrinsic power consumption

Delivery Content / Lieferumfang

1 x Rittal 7979.310 16A 3,7KW High-end IT Rack Power Distribution PDU
